What Do The Parameters Of The Product Mean?

For those of you who may only know how to use your power station or solar generator but aren't very familiar with its features, don't worry—we're here to help! In this guide, we'll explain some of the parameters that our customers often ask about and how they affect your experience while using our power station.

In-depth Product Specification

The specification list is divided into three sections: Output, Input, and General Info.

Output

AC Output

1. 100V–120V: Powers appliances within this voltage range.
2. 50Hz/60Hz: Switchable frequency output.
3. Max 2500W: Continuous power output capacity.
4. Surge 5400W: Peak/startup wattage the unit can handle briefly.
5. Bypass Mode 2500W: This feature allows the power station to automatically switch from its internal battery to an external or utility power source. In bypass mode, the Mega 2 supports up to 2500W of output.

DC 12V & Cigarette Lighter Output: Provides up to 120W (12V 10A).

USB-A Output: Max 18W. (5V 3A / 9V 2A / 12V 1.5A)

USB-C Output: Max 100W. (5V–20V, up to 5A)

Anderson Output: Max 360W (12V 30A)

Input

AC Input

1. 100V–120V: AC charging voltage range.
2. 60Hz: Standard AC frequency.
3. 13A Max: Maximum input current—do not exceed.
4. 1600W Max: Maximum AC charging power.

Solar Input

5. 12V–148V: Overall solar charging voltage range supported.
6. MPPT 18V–140V: Optimized voltage range for MPPT charging.
7. 15A Max: Maximum supported current.
8. 2100W Max: Maximum solar charging power.

Cigarette Lighter Input

9. 12V–15V: Voltage range for car charging.
10. 8A Max: Maximum supported current for this input.

General Info

Battery Capacity

1. 2048Wh: Total energy capacity.
2. 51.2V / 40Ah: Battery voltage and amp-hour rating.

Battery Type

3. LiFePO4: Lithium Iron Phosphate for safety and longevity.
